2.1absolute maximum

input voltage(Vin)

Non-working state, continuous input

0

315

VAC

Maximum output power (Pomax)

under permitted working conditions

1200

W

2.2Input properties

Nominal input voltage range(with wine)

100

220

240

VAC

Input operating voltage range

85

290

VAC

Input voltage undervoltage protection point

79

VAC

Input voltage undervoltage recovery point

84

VAC

Input voltage overvoltage protection point

Tbd

VAC

Input voltage overvoltage recovery point

Tbd

VAC

Input voltage frequency range

47

50/60

63

Hz

Power factor (PF)

110VAC~240VAC,tow100% ofratedload

0.95

0.98

Input total harmonic currentTHD

Vonom, 100% of rated load

5

10

%

Input maximum current(Iimax)

Input voltage tested under various input and output conditionsstream valid value;Tested according to derating standards

Tbd

A

Input surge current

With wine

40

A

Grounding method

Aluminum substrate applicationPE

2.3  Output characteristics

Output voltage setting accuracy(pull)

50% Ion, Wine

11.76

12

12.24

VDC

Output voltage regulation accuracy

Output under various input and output loadsvoltage range

-3

+3

%Vo

Output voltage adjustment range(TRIM)

Please refer to the attached drawing for the adjustment method.Aftergreater thanPomax

10.8

14.4

VDC

Nominal load(Ion)

100

A

Output power

12VRated outputoutcurrent100A;10.8-12V,loseoutThe current does not exceed100A;12-14. PM,The output power does not exceed1200W

source effect(Vov)

tion~Vimax,Ion

±1

%Vo

loading effect(Vol)

0%~100%Ion,With wine

±2

%Vo

Output overcurrent protection

protection method

self-recovery

Protection point range

max

105

140

A
